遙遙領先MTRONPTI攜M2520系列振蕩器王者歸來

來源：*** 查看手機網址

掃一掃!

掃一掃!

瀏覽：- 發布日期：2023-10-08 10:12:30【大中小】

分享到：

遙遙領先MTRONPTI攜M2520系列振蕩器王者歸來

MtronPTI麥特倫皮今天推出新產品，M2520系列小尺寸差分輸出晶體振蕩器。有源晶振M2520系列振蕩器支持小于100fs的均方根抖動，頻率容差極小，低至+/-20ppm。該振蕩器具有2.5x2.0mm的小尺寸，支持-40至+85C的寬工作溫度范圍，標準和定制輸出頻率最高可達212.5 MHz，石英晶振，六腳貼片晶振，有源晶振，差分晶體振蕩器。具有超小型，輕薄型，低抖動，低功耗，低電源電壓，低耗能，低電平，低損耗，低相位噪聲等特點。非常適合空間有限、環境條件惡劣的應用。M2520系列適合各種應用，包括光模塊、網絡、服務器、存儲、電信和其他要求低抖動和小尺寸的應用。

MtronPTI晶振廠家提供各種精密晶體諧振器、晶體振蕩器、濾波器和集成微波組件解決方案。MtronPTI是ISO 9001:2015和AS9100 Rev. D認證組織。
M2520系列振蕩器特點:
頻率范圍：13.5MHz至212.5MHz
LVPECL和LVDS輸出選項
+/-20ppm穩定性，提供其他選項
<100fs RMS jitter @ 156.25MHz
電壓：3.3V或2.5V
小體積晶振尺寸：2.5x2.0mm表貼封裝，6焊盤布局貼片晶振
工作溫度范圍:-45℃至85℃

應用：

10G千兆以太網交換機/路由器
光學模塊/光收發器
電信和數據通信
工業和儀器儀表

遙遙領先MTRONPTI攜M2520系列振蕩器王者歸來

MtronPTI today introduced the M2520 series small form factor differential output crystal oscillator. M2520 series oscillators support less than 100fs RMS Jitter with extremely tight frequency tolerance down to +/-20ppm. This oscillator has a small form factor of 2.5 x 2.0mm, supports a wide operating temperature range of -40 to +85C, and has standard and custom output frequencies up to 212.5 MHz, making it ideal for applications where space is limited and environmental conditions challenging. The M2520 series is suitable for a variety of applications, including optical modules, networking, servers, storage, telecom, and other applications which require low jitter and a small form factor.

MtronPTI offers a broad line of precision crystal resonators, oscillators, filters, and Integrated Microwave Assembly solutions. MtronPTI is an ISO 9001:2015 and AS9100 Rev. D certified organization.

Features：
Frequency range: 13.5MHz to 212.5MHz
LVPECL and LVDS output options
+/-20ppm stability, other options available
<100fs RMS jitter @ 156.25 MHz
3.3V or 2.5V
2.5 x 2.0 mm surface mount package with 6 pad layout
Operating temperature range: -45°C to 85°C
Applications：
